Freya router

Customer Premises Equipment

The ultimate home interface to HD satellite TV that integrates broadband internet access via satellite. Freya lets home users centralize their satellite services into one device.

Freya is the cost-effective option for operators offering both satellite TV and internet and gives the operator the combination of a high-end zapper STB and a high-performance satellite router for hybrid Internet over satellite services. A selection of return channels can be combined with a high throughput DVB-S2/ACM forward link for well performing Internet services.

Technical Specification

Overview

TV interface for large-screen interaction.
Integrated web based (http) user interface.
No software/drivers need to be installed on connected computers.
An integrated DHCP server provides private IP addresses to all connected computers.
Linux based operating system.

Applications

Satellite TV services
Hybrid Internet over satellite
Satellite multicast reception

User Interface (TV display)

Basic TV application for viewing and channel handling
Possibility to apply external middleware for a customized interface (case by case, please contact us)

Performance

Up to 60 Mbit/s from satellite to LAN

Processor & Memory

Ali M3527 SOC
512 MB DDR3 1600Mhz RAM
256 MB non-volatile flash memory

Satellite front-end

Support for DVB-S2/ACM and DVB-S
Input frequency range: 950 MHz to 2150 MHz

Symbol rate support:
1-68,4 Msym/s (QPSK, 8PSK, 16APSK)
1-53.9 Msym/s (32APSK)

Modulation support: DVB-S2 modcod range

Power Supply

External AC/DC converter: 230VAC/12VDC 2A

Mechanics (excluding connectors)

HxDxW: 205x145x38

Connectors / Rear Panel

2x RF input connector, F connector (75 Ohm) for satellite feed
1x HDMI v.1.3 (1080p) connector
2x Ethernet ports, 100Mbit/s (RJ-45)
2x USB-A 2.0 (device) ports
1x Mains AC/DC power supply adapter inlet 12V through DC plug
1x Factory reset button

Accessories

User manual in English
Remote control
Optional accessories (extra cost):
Ethernet cable (2m)
HDMI cable
Power supply

Connectivity

Ethernet ports for WAN and LAN
Wi-Fi Access Point 802.11n

Software

Linux operating system
TV middleware for the STB part
Web based user interface for the router part
Integrated client for the Mimir HUB
DHCP server for simple IP address management

Front Panel

1x LED for power
1x LED for return channel connection
1x LED for Mimir connection
1x LED for satellite lock
