Odin F-50 router

Customer Premises Equipment

Odin is a cost effective, high performance satellite router for hybrid internet over satellite services. DVB-S2 is used for downlink and can be combined with a variety of terrestrial return channels. Depending on the technology used for the return channel, Odin will either integrate a mobile network interface or an internal dial-up modem.

Odin is designed to operate with broadcasting satellites; it is equipped with a state of the art DVB-S2 demodulator and advanced IP over satellite optimization tools including ACM.  The principles of its implementation make Odín the most flexible and cost-efficient hybrid broadband modem in the market.

Key Business Benefits

  • Eliminates need to deploy additional infrastructure - furnishes significant operator cost savings and delivery of highly cost-efficient broadband
  • Enables rapid deployment of robust, satellite-based internet services to regions grappling with insufficient infrastructure or capacity
  • Furnishes competitive VSAT alternative - no need for satellite communications license

Technical Specifications

Overview

Integrated web based (http) user interface.
No software/drivers need to be installed on connected computers.
An integrated DHCP server provides private IP addresses to all connected computers.
Linux based operating system.

Applications

Hybrid Internet over satellite
Satellite multicast reception

Performance

Up to 60 Mbit/s from satellite to LAN

Processor & Memory

Ali M3527 SOC
512 MB DDR3 1600Mhz RAM
256 MB non-volatile flash memory

Satellite Front-End

Support for DVB-S2/ACM and DVB-S
Input frequency range: 950 MHz to 2150 MHz

Symbol rate support:
1-68,4 Msym/s (QPSK, 8PSK, 16APSK)
1-53.9 Msym/s (32APSK)

Modulation support: DVB-S2 modcod range

Connectivity

Ethernet ports for WAN and LAN
Wi-Fi Access Point 802.11n

Power Supply

External AC/DC converter: 230VAC/12VDC 2A

Mechanics (excluding connectors)

HxDxW: 205x145x38

Connectors / Rear Panel

1x RF input connector, F connector (75 Ohm) for satellite feed
2x Ethernet ports, 100Mbit/s (RJ-45)
2x USB-A 2.0 (device) ports
1x Mains AC/DC power supply adapter inlet 12V through DC plug
1x Factory reset button

Accessories

User manual in English

Optional accessories (extra cost):
Ethernet cable (2m)
Power supply

Software

Linux operating system
Web based user interface
Integrated client for the Mimir HUB
DHCP server for simple IP address management

Front Panel

1x LED for power
1x LED for return channel connection
1x LED for Mimir connection
1x LED for satellite lock
